Descripción del producto
DOT 3 Glycol-Ether Brake Fluid. It provides a high dry and wet boiling point to resist vapour lock, controlled low-temperature fluidity for responsive braking, excellent corrosion protection for brake-system metals and compatibility with brake rubber components for safe, reliable braking performance.
Principales prestaciones
| High dry boiling point
high dry ERBP resists vapour lock under hard, repeated braking. |
High wet boiling point
maintains a safe boiling point as the fluid absorbs moisture in service. |
| Low-temperature fluidity
controlled low-temperature viscosity for responsive cold braking and ABS/ESP. |
Protección contra la corrosión
protects brake-system metals against rust and corrosion. |
| Rubber compatibility
compatible with standard brake cups, seals and hoses. |
Miscible with DOT 3/4/5.1
mixes with other glycol-ether brake fluids (not silicone DOT 5). |
Aplicaciones y nivel de rendimiento
| Aplicaciones | General hydraulic disc and drum brake and clutch systems specifying an FMVSS 116 DOT 3 brake fluid. |
| Especificaciones | FMVSS 116 DOT 3 — US federal DOT 3 brake fluid standard. SAE J1703 — SAE DOT 3 brake fluid specification. ISO 4925 Class 3 — international DOT 3 brake fluid classification. Reliable boiling point — dependable dry and wet boiling points for general braking. Broad compatibility — suitable for general passenger-car brake systems. |
| Idoneidad para fabricantes de equipos originales (OEM) | Hydraulic brake and clutch systems specifying FMVSS 116 / SAE J1703 / ISO 4925 Class 3 (DOT 3). Use only the grade specified by the vehicle manufacturer. |
| Aviso importante | Brake fluid is hygroscopic: keep containers sealed and do not reuse. Do not mix with silicone (DOT 5) fluid. ”Suitable for” does not mean official approval. Follow the vehicle manufacturer’s specification. |
| Propiedad | Método de ensayo | Objetivo Valor típico |
| Aspecto / Color | Visual | Clear to amber |
| DOT Grade | FMVSS 116 | DOT 3 |
| Dry Equilibrium Boiling Point (ERBP) | ISO 4925 | ≥ 230°C |
| Wet Equilibrium Boiling Point | ISO 4925 | ≥ 145°C |
| Kinematic Viscosity @ -40°C | ISO 4925 | ≤ 1,500 mm²/s |
| Viscosidad cinemática a 100°C | ISO 4925 | ≥ 1.5 mm²/s |
| pH Value | ISO 4925 | 7.0 – 11.5 |
| Corrosion Resistance | ISO 4925 | Pasar |
| Rubber (SBR) Compatibility | ISO 4925 | Pasar |
Nota: Los valores objetivo indicados anteriormente son valores típicos del producto y se ofrecen únicamente a título informativo; los datos definitivos de producción están sujetos a la ficha técnica oficial de KATMOTO (TDS) y al informe de ensayos de laboratorio.
